2025 Johnford ST160-BMCY

The 2025 Johnford ST160-BMCY is a reliable used multi-tasking CNC lathe designed for versatility and precision in industrial machining tasks. With a swing over bed of 36.2 inches and a maximum swing over cross slide of 27.6 inches, it accommodates a wide range of workpieces. The machine offers a substantial bar capacity of 4.6 inches and features a spindle nose of A2-11 with a spindle bore of 5.2 inches, allowing for efficient material handling and processing. Equipped with a 64.3 hp spindle motor and capable of reaching up to 2000 rpm across four gear ranges, the ST160-BMCY provides robust performance. Its axis travels include 14.6 inches on the X-axis, 3 inches on the Y-axis, and an extensive 159.4 inches on the Z-axis, combined with a tailstock body travel of 141.7 inches and a spindle travel of 5.9 inches, offering comprehensive coverage for complex multi-tasking operations. This CNC lathe measures approximately 390 inches in length, 98.6 inches in width, and 114 inches in height, with an approximate weight of 53,020 lbs. It requires power specifications of 65 kVA with a max amp load of 170A at 220 volts, 3-phase, 60 Hz. Ideal for facilities requiring a reliable, high-capacity lathe, the Johnford ST160-BMCY stands as a valuable investment for enhanced productivity and precision.
