2008 Mazak Cybertech Turn 5500M with 14.75″ Bore Multi-Tasking CNC Lathe for Oil Industry
Sold
2008 Mazak Cybertech Turn 5500M with 14.75″ Bore Multi-Tasking CNC Lathe for Oil Industry
Description
EQUIPPED WITH: - Mazatrol 640MT Pro - Hinge Chip Conveyor - 213 Hi Pressure Coolant - C Axis 0.001 deg. Incr. - 14.6” Spindle Bore - Multi Tap Transformer 230V-260V - Prep for Rear Manual Chuck – 33.46” Max - Long Boring Bar Stocker – (2) Bar - Long Boring Bar Holder w/o Bar 80mm ID for LBB Stocker - Long Boring Bar Holder w/o Bar 100mm ID for LBB Stocker - Manual Tool eye for 34” - Extended Tailstock - Re – Threading Function - Thread Start Point Function - SMW Steady Rest K6-Z - 33.4″ Schunk TB850 Extended Stroke Air Chuck Pckg - Rota Classic P800 4-Jaw Independent Manual Chuck for Rear - Tooling and Manuals
Specifications
| Manufacturer | Mazak |
| Model | Cybertech Turn 5500M |
| Year | 2008 |
| Condition | Used |
| Stock Number | XL07282023 |
| Control type | Mazatrol 640MT Pro |
| Maximum Swing | 36.2 |
| Bar capacity | 14.76 |
| Chuck diameter | 33.4 |
| Live tooling | Yes |
| Lathe type | Lathes, Combination, CNC Turning Center, Multi Tasking, Ideal for Oil Industry" |
| Maximum swing | 36.02” |
| Swing over cross slide upper turret | 27.56” |
| Maximum machining diameter upper turret | 31.89” |
| Maximum machining length upper turret | 120” |
| Maximum support mass chuck work | 13228 lbs |
| Maximum support mass shaft work | 7716 lbs |
| Rotating speed (min-1) | 2 to 500 |
| Through-hole diameter | 14.76” |
| Spindle nose | JIS A2-20” |
| Motor output (Continuous/Half-hourly rating) | 47/37 kW |
| Maximum torque | 8482 ft-lbf |
| Spindle hole type (MT) | No. 6 |
| Maximum thrust power | 7868.3 lbf |
| Type | Bolt fixing type |
| Number of tools mounted | 12 |
| Tool size outside turning | 1.5” |
| Tool size inside turning | 2.5” |
| Tool size milling drill | 40mm |
| Tool size milling tap | M30 |
| Tool size end-mill | 40mm |
| Indexing time (s) | 0.4/step |
| Mill spindle speed (min-1) | 25-3000 |
| Milling output (Continuous/Half-hourly rating) | 11/7.5 kW |
| Maximum torque of mill spindle (ft.lbf) | 103.3 |
| Rapid traverse X1 | 945 IPM |
| Rapid traverse Z1 | 1181 IPM |
| Rapid traverse Axis of tailstock | 236 IPM |
| X Axis Travel | X1 – 21.26” |
| Z Axis Travel | Z1 – 123.23” |
| Movement stroke tailstock | 120.08’’/100.39 (with work rest) |
| Coolant tank capacity (ft3) | 28.25” |
| Power requirement (continuous) | 85.81 kVA |
| Air pressure | 70 psi |
| Total air required (regularly) | 12.4 ANR |
| Height of centers | 51.97” |
| Length | 287.99” |
| Width | 143.03” |
| Height | 112.99” |
| Floor space required (ft2) | 228.19” |
| Mass (including oil pan) | 55997 lbs |
